A Pune quotation for a shop floor crane is meaningful only when it identifies the load radius, hook positions, mobility, floor conditions, and every extra charge. By the end, you will be able to compare realistic purchase budgets, test a supplier’s availability claim, and request a configuration that fits your floor rather than relying on a single capacity number.
Key takeaways
- Budget ₹20,000–₹75,000 for basic 0.5–2 tonne manual hydraulic cranes.
- Request an all-in quote covering freight, GST, installation, testing, and commissioning.
- Measure floor capacity, aisle width, door clearance, lift height, and turning space.
- Confirm stock, fabrication time, dispatch date, and delivery terms before ordering.
What should a shop floor crane cost in Pune after all charges?
Budgeting ranges for shop floor crane price in Pune are ₹20,000–₹75,000 for basic 0.5–2 tonne manual hydraulic cranes, ₹60,000–₹2,00,000 for heavier or better-finished 2–5 tonne mobile cranes, and ₹75,000–₹3,00,000 for portable gantry cranes. These are indicative budgeting ranges, not current firm prices or guaranteed all-in totals.
| Type | Indicative equipment range | Main price drivers |
|---|---|---|
| 0.5–2 tonne manual hydraulic crane | ₹20,000–₹75,000 | Fixed boom, wheels, finish, lifting height |
| 2–5 tonne mobile crane | ₹60,000–₹2,00,000 | Frame strength, wheel arrangement, reach, finish |
| Portable gantry crane | ₹75,000–₹3,00,000 | Span, hook height, capacity, adjustment, assembly |
Telescopic or adjustable booms cost more because the boom, locking pins, cylinder, and frame must support several load-radius combinations. Larger wheels, powered travel, greater hook height, and installation also raise the final amount.
Request a line-by-line Pune quotation showing whether it includes:
- 18% GST, freight, and unloading
- Assembly, commissioning, and floor anchoring
- Inspection and proof-load testing
- Operator training and spare parts
Check the terminology before comparing offers. Safe working load is the permitted operating load; proof-test load is used during testing and is not an operating rating; ultimate structural capacity is the failure limit, not a usable capacity. A low ex-works price is therefore not the installed cost.
Which crane configuration should you ask a Pune supplier to quote?
Ask a shop floor crane supplier in Pune to quote a defined configuration, not merely “1,000–2,000 kg capacity.” State:
- Rated load and load-centre distance
- Minimum and maximum hook position and maximum hook height
- Boom length, each boom extension, and maximum outreach
- Required under-clearance
- Overall length, overall width, wheel diameter, turning radius, and unladen weight
A 2,000 kg rating can become unusable when the load moves outward. Require a load chart showing the permitted load at every boom position, not one capacity figure. Also ask whether the quoted capacity is safe working load, proof-test load, or ultimate structural capacity; proof-test load is for testing, not operation.
| Configuration | Main difference | Suitable when |
|---|---|---|
| Fixed boom | One reach and simpler mechanism | The lifting radius rarely changes |
| Telescopic boom | Adjustable reach with several rated positions | You need variable outreach and accept higher cost |
| Wheeled frame | Manually pushed mobility | Loads move short distances with the boom low |
| Counterbalanced frame | Stability from rear counterweight | Front reach matters more than compactness |
| Folding crane | Stores in less space | The crane must be parked between jobs |
| Fixed jib crane | Anchored rotation around one base | Loads stay within one workstation |
| Portable gantry | Frame travels or assembles around the load | You need lifting without floor anchoring |
| Small electric overhead crane | Powered lifting on installed runway | Loads must travel suspended through a defined path |
Specify whether the crane only lifts and places loads or must travel beneath a suspended load. A mobile crane is not the right substitute for an overhead system in the latter case.
How much manual effort will the crane require during lifting and movement?
A manual shop floor crane in Pune is practical only when lift frequency, travel distance, and floor condition match human effort. Ask the supplier for pump strokes or handle force, lifting time, lowering control, maximum push force while loaded, and whether positioning requires a second person.
A crane that lifts easily but needs excessive force to roll is not workable.
| Mechanism | Strength | Effort and limitation |
|---|---|---|
| Hydraulic hand pump | Direct lifting with controlled lowering | State strokes per lift; slow for repeated cycles |
| Hand winch | Fine cable control and useful height | State handle force and lifting time; cable care matters |
| Chain-operated mechanism | Simple manual hoisting | State chain pull and lowering control; operator fatigue rises with load |
Specify these items before accepting a low quotation:
- Hydraulic-cylinder protection, relief-valve arrangement, boom-locking pins, hook safety latch, and wheel brakes.
- Frame material, weld quality requirements, weld inspection, spare seals, and a maintenance manual.
- Wheel material, wheel diameter, total wheel capacity, and steering arrangement.
Small swivel castors roll easily when empty but can demand high push force, mark floors, or feel unstable under load. Larger wheels reduce push force and floor damage on uneven concrete, but need more turning space and cost more.
Use a mobile hydraulic crane for short repositioning with the boom low and the route clear, not routine travel with a high suspended load. Manual operation does not remove the need for a rated load chart or stability verification.
Will the crane fit your floor, aisles, doors, and lifting path?
A crane is site-suitable only when its dimensions, point loads, stability, and travel route match your floor and building. Measure these before accepting a quotation:
- Concrete grade, cracks, joints, spalling, surface condition, and allowable point loading
- Floor levelness, slope, ramp gradient, and the supplier’s permitted travel limits
- Aisle width, door width and height, turning radius, and required under-clearance
- Pits, drains, trenches, floor steps, dock edges, and overhead beams, lights, pipes, and sprinklers
- Maximum load, load-centre distance, hook heights, outreach, and whether travel occurs with the load suspended
| Site factor | What to obtain | Why it matters |
|---|---|---|
| Wheel or outrigger loading | Maximum wheel load or outrigger reaction | Compare it with allowable point loading; total crane weight is not enough |
| Stability geometry | Counterweight position, wheel spacing, boom outreach, load-centre distance | A longer reach or sloping floor reduces the stability margin |
| Reach capacity | Load chart and stability or design calculation at the farthest required reach | Short-boom capacity does not prove safe operation at maximum outreach |
Ask for the load chart for every boom position, not one headline capacity. Before production use, walk the unloaded crane through the route, test brakes and wheel contact, check lowering control, hook latch, and boom locks, then observe controlled lifting, travel, and lowering with a test load.
Stop if it tilts, drifts, binds, or marks the floor.
How quickly can you buy and receive a shop floor crane in Pune?
Ready stock is the fastest route: a standard manual hydraulic unit can be dispatched in days when its capacity, boom, wheels, and finish are available. Custom frames, special wheels, non-standard hook heights, painted finishes, portable gantries, and powered equipment commonly require several weeks.
| Option | Lead time | Confirm before ordering |
|---|---|---|
| Standard manual hydraulic crane | Dispatch in days if in stock | Actual stock status and dispatch date |
| Custom manual crane or portable gantry | Several weeks | Manufacturing completion date |
| Powered equipment or special finish | Several weeks | Completion, testing, and commissioning dates |
Ask the supplier to state site-delivery coverage, unloading responsibility, assembly time, commissioning plan, and every excluded charge in writing.
Before you buy a shop floor crane in Pune, request design calculations where relevant, a rated load chart, material and weld details, inspection records, test certificate, proof-load test record, operating instructions, maintenance schedule, and the design standards used.
Compare a shop floor crane supplier in Pune such as Dofort on specification clarity, site support, and after-sales documentation—not only the equipment line item.
- Maximum load, load-centre distance, radius, hook height, and required under-clearance
- Floor condition and slope, aisle and door dimensions, and turning radius
- Duty cycle and whether the load travels while suspended
- Stock status, manufacturing completion, dispatch, delivery, unloading, assembly, and commissioning dates
A written answer prevents an apparently available crane from becoming a delayed or unusable installation.
Related products
 | Manual Equipment Capacity: 1000-2000 Kg Lift Height: 2000 mm View product → |
 | Loading / Lifting Equipment Industrial Cranes View product → |
Frequently asked questions
What should a shop floor crane cost in Pune after all charges?
Indicative budgets are ₹20,000–₹75,000 for basic 0.5–2 tonne manual hydraulic cranes, ₹60,000–₹2,00,000 for heavier or better-finished 2–5 tonne mobile cranes, and ₹75,000–₹3,00,000 for portable gantry cranes. Ask the supplier to separate the crane price from freight, GST, installation, testing, and commissioning charges.
Which crane configuration should you ask a Pune supplier to quote?
Give the supplier the safe working load, load dimensions, lift height, required reach, movement surface, aisle width, door height, and lifting frequency. Request separate quotes for a manual hydraulic mobile crane, a heavier mobile crane, and a portable gantry crane when each configuration could suit the job.
How much manual effort will a shop floor crane require during lifting and movement?
A manual hydraulic crane requires the operator to position the crane, pump or operate the hydraulic system, steer or push the load, and control lowering. Ask for the pump type, wheel arrangement, steering method, unloaded and loaded operating effort, and floor condition assumed in the quote.
Will the crane fit your floor, aisles, doors, and lifting path?
Check rated floor capacity, aisle width, door height and width, turning radius, maximum hook height, minimum hook height, outreach, and the crane's overall dimensions. Mark the full travel and lifting path before ordering, including space for the load and operator.
How quickly can you buy and receive a shop floor crane in Pune?
Availability depends on whether the quoted model is in stock, needs fabrication or modification, and requires site installation or testing. Ask for written stock status, manufacturing completion date, dispatch date, delivery location, installation date, and the documents supplied with the crane.
